HMOR series high temperature bending tester
The equipment is composed of heating furnace, loading mechanism, automatic injection mechanism and control system, with compa
The equipment is composed of heating furnace, loading mechanism, automatic injection mechanism and control system, with compa
The equipment is composed of heating furnace, loading mechanism, automatic injection mechanism and control system, with compact structure, novel shape and convenient sample loading operation. The heating furnace has good heat preservation performance, energy saving and high efficiency. The loading part adopts the parallel bar type vertical loading mechanism with patent technology, which is a kind of non gap loading mechanism. It adopts frequency conversion speed regulation, and can completely carry out constant rate loading according to different loading rates. The injection mechanism is accurate and easy to operate. It has the characteristics of wide test range, high precision, less misoperation, high efficiency, stable and reliable operation. The six samples can be operated automatically within 15 minutes, which is 15 minutes shorter than that of frame type bending compression samples, which can meet the loading rate requirements of the standard in the whole range. (slide type and mechanical switch type are easy to miss sample position, resulting in inaccurate sample position)
The equipment is used to measure the high temperature bending strength of refractories. The equipment is manufactured in strict accordance with the requirements of international standards iso5013, iso5014 and national standard GB / t3002 "test method for flexural strength at high temperature". It is composed of heating furnace, loading mechanism, automatic injection mechanism and control system. IPC industrial computer is used for automatic control, which has friendly interface, high precision of temperature control and loading, dynamic real-time display of temperature time and pressure time curves, and the original data can be converted into excel storage format, and the test report can be read and printed at any time. The bending strength of the material can be tested in nitrogen, argon, air and carbon.
型号/参数 Model/specification | HMOR-03AG | HMOR-03A | HMOR-03AZ |
加荷方式 Load mode | 双杠杆 Double lever type | 门型丝杠直压 Door-type direct pressure | 垂直加压 Press vertically |
最大负荷 Max.Load(kN) | 10 | ||
测量精度 Measuring accuracy(%) | 1 | ||
使用温度 Working temperature(%) | 1600 | 1450 | |
升温速率 Heating-up rate(℃/min) | 0~10 | ||
试样个数 Quantity of samples(mm) | 6(25×25×150)&4(40×40×160) | ||
炉膛尺寸 Hearth size(mm) | 530×240×210 | ||
主机尺寸 Size of mainframe(mm) | 1800×750×1900 | 1800×120×1950 | 1700×950×2100 |
电源 Power supply | 380V 50Hz 25kW | ||
重量 Weight(kg) | 850 | 1300 | 800 |
