NMJ-01 normal temperature wear resistance testing machine
The machine is suitable for measuring the relative wear resistance of refractory products, refractory castables and refractor
The machine is suitable for measuring the relative wear resistance of refractory products, refractory castables and refractory plasticity. The equipment refers to the technical requirements of GB / T 18301 "test method for abrasion resistance of refractories at room temperature" (the standard is equivalent to ASTM (c704) standard). The equipment is composed of main engine, air compressor and electronic balance.
| 磨损介质 Abrading media | 36号粒度黑色碳化硅 NO.36 SiC granularity |
| 喷砂量 Spraying sand capacity(g) | 1000±5 |
| 喷砂时间 Spraying sand time(s) | 450±5 |
| 工作室尺寸 Size of working pressure chamber(mm) | 220×300×480 |
| 空压机功率 Power of compressor(kW) | 8 |
| 空压机额定排气量 Rated air capacity(m³/min) | 1 |
| 空压机额定压力 Rated pressure of compressor(MPa) | 1 |
| 主机尺寸 Mainframe size(mm) | 460×620×1300 |
| 重量 Weight(kg) | 60 |
