TQD-02 air permeability tester
透气度测定仪适用于室温下测定致密定形耐火制品的透气性。对定形隔热耐火制品透气性的测试也可参照使用。该设备是按国家标准GB/T 3000《致密定形耐火制品透气度试验方法》的要求设计制造。 通气量范围 Air flow range(cm³/mi
The air permeability tester is suitable for measuring the air permeability of dense shaped refractory products at room temperature. The air permeability test of shaped insulating refractory products can also be referred to. The equipment is designed and manufactured according to the national standard GB / T 3000 "test method for air permeability of dense shaped refractory products".
| 通气量范围 Air flow range(cm³/min) | <50 |
| 试验温度 Working temperature(℃) | 室温 room temperature(10～35) |
| 试样尺寸 Sample size(mm) | φ50×50 |
| 气源输出压力 Gas output pressure(MPa) | 0.1～0.4 |
| 充气压力 Inflation pressure(MPa) | 0.1-0.15 |
| 测试气体 Atmosphere of hearth | air,N₂ |
| 主机尺寸 Size of mainframe(mm) | 510×600×680 |
| 重量 Weight(kg) | 30 |
