KCJ-01 grooving machine
The grooving machine is a kind of special equipment used in the laboratory of refractory production enterprises and scientifi
The grooving machine is a kind of special equipment used in the laboratory of refractory production enterprises and scientifi
The grooving machine is a kind of special equipment used in the laboratory of refractory production enterprises and scientific research institutions for hot wire heat conduction and sample preparation. The equipment has reasonable structure and convenient operation. It can be equipped with single and double diamond saw blades. When equipped with parallel double saw blades, the distance between the saw blades is 15mm, the thickness of the saw blade is > 1mm, the sample can move three-dimensional with the sample table, and the depth of the sample groove can be adjusted.
主轴直径 Main shaft diameter(mm) | φ20 |
主轴转速 Main shaft speed(r/min) | 2800 |
工作台面 Workbench(mm) | 300×380 |
工作台形程 Workbench range(mm) | 300 |
锯片上下形程 Saw bit up and down range(mm) | 50 |
锯片直径 Saw bit diameter(mm) | φ100 |
功率 Power(kW) | 0.18 |
电源 Power supply | 三相380V 0.53A 50Hz |
外形尺寸 Size of mainframe(mm) | 1300×520×1500 |
净重 Weight(kg) | 50 |
