KJX-02 alkali resistant experimental furnace
The equipment is used to measure the alkali resistance of refractories. The equipment is made in accordance with the requirem
The equipment is used to measure the alkali resistance of refractories. The equipment is made in accordance with the requirements of GB / T 14983 test method for alkali resistance of refractories. Fully closed furnace body, heat-resistant steel furnace tube, safe and durable. The control system realizes automatic control of the whole process, with high temperature control precision and stable and reliable equipment.
| 使用温度 Working temperature(℃) | 1100 |
| 短时最高温度 Max.temperature(℃) | 1300 |
| 炉管尺寸 Size of furnace tube(mm) | φ100×250 |
| 升温速率 Heating-up Rate(℃/min) | 0～8 |
| 保温温度精度 Temperature accuracy in soaking(℃) | ±2 |
| 电源 Power supply | 380V 50Hz 10kW |
| 主机尺寸 Size of mainframe(mm) | 1300×700×1400 |
| 重量 Weight(kg) | 450 |
