NHD series refractoriness test furnace
The equipment is used to measure the refractoriness of refractories. The range of determination is 1580 ~ 1800 ℃. The equipme
The equipment is used to measure the refractoriness of refractories. The range of determination is 1580 ~ 1800 ℃. The equipme
The equipment is used to measure the refractoriness of refractories. The range of determination is 1580 ~ 1800 ℃. The equipment is manufactured in accordance with the national standard GB / T 7322 test method for refractoriness of refractories. Nhd-02 is heated by carbon particles. The furnace body, upper and lower electrodes are made of stainless steel, which is durable. Nhd-03p and nhd-04p adopt imported molybdenum disilicide heating elements and imported all fiber lining, stainless steel furnace shell and energy-saving furnace body. Camera horizontal imaging, through the camera automatic judgment of the cone curve, automatic recording of test data, can simultaneously carry out the sample comparison test and direct reading test. The machine is compact in structure, small in area, novel in shape, easy to load and operate. It has the characteristics of wide test range, high precision, less misoperation, high efficiency, stable and reliable operation.
型号/参数 Model/specification | NHD-02 | NHD-03P | NHD-04P样品可旋转 |
使用温度 Working temperature(℃) | 1800 | ||
短时最高温度 Max.temperature(℃) | 1850 | ||
试样个数 Quantity of sample | 2~6 | ||
锥盘转速 Rotary speed of cone(r/min) | 3 | / | 3 |
电源 Power supply | 380V 50Hz 40kW | 220V 50Hz 5kW | 220V 50Hz 5kW |
冷却水源 Cooling-water supply | φ10mm,>0.1MPa | / | / |
主机尺寸 Size of mainframe(mm) | 520×650×1100 | 820×560×1360 | 800×570×1450 |
控制柜尺寸 Size of control cabinet(mm) | 500×510×1400 | 1400×650×800 | 650×1400×800 |
重量 Weight(kg) | 500 | 350 | 400 |
