RNMJ series hot wear resistance testing machine
The machine is suitable for the measurement of high temperature wear resistance of refractory products, as well as the determ
The machine is suitable for the measurement of high temperature wear resistance of refractory products, as well as the determination of relative high temperature wear resistance of refractory castables and refractory plasticity. The equipment refers to the technical requirements of GB / T 18301 "test method for abrasion resistance of refractories at room temperature" (the standard is equivalent to ASTM (c704) standard). The equipment is composed of heating furnace, injection device, air compressor, electronic balance and control system.
| 型号/参数 Model/specification | RNMJ-01 | RMNJ-03 |
| 高压室压力 Working pressure in high pressure chamber(MPa) | 0.448 | |
| 稳压室压力 Working pressure in steady pressure chamber(MPa) | 0.016±0.001 | |
| 磨损介质 Abrading media | 36号粒度黑色碳化硅或刚玉砂 NO.36SiC granularity or corundum sand | |
| 喷砂量 Spraying sand capacity(g) | 1000±5 | |
| 喷砂时间 Spraying sand time(s) | 900±20 | |
| 最高温度 Max temperature(℃) | 1450 | |
| 升温速率 Heating-up rate(℃/min) | 0～15 | |
| 试样个数 Quantity of sample | 1 | 3 |
| 保温温度精度 Temperature accuracy in soaking(℃) | ±2 | |
| 空压机额定排气量 Rated air capacity(m³/min) | 1 | |
| 空压机额定压力 Rated pressure of compressor(MPa) | 1 | |
| 主机尺寸 Size of mainframe(mm) | 820×600×1550 | 820×810×1600 |
| 控制柜尺寸 Size of control cabinet(mm) | 550×600×1500 | |
| 电源 Power supply | 380V 50Hz 8kW | 380V 50Hz 10kW |
| 重量 Weight(kg) | 400 | 450 |
